Technical Data
| Product Model | X1100 | X1040 | X1020 | X1010 |
| Pore Size (μm) | 1.0 | 0.45 | 0.22 | 0.10 |
Absolute Ethanol First Bubble Pressure (MPa) | 0.03 | 0.07 | 0.12 | 0.16 |
| Water Flow Rate （m3/m2·hr@0.02MPa, 25℃） | 8.0 | 4.0 | 3.0 | 1.0 |
| Reinforcement Material | Non(1), PP(3), PET(4) | |||
| Thickness (μm) | 20 ~ 200 | |||
Explanation:
1.?Product implementation standard: QB/T01-2015 "PTFE microporous membrane"
2. The above first bubble pressure and flow rate data are typical values
3. The X in the product model row indicates reinforement material?
