Technical Data
| Product Model | X1100 | X1120 | X1300 | X1500 |
| Pore Size (μm) | 1.0 | 1.2 | 3.0 | 5.0 |
Water Flow Rate (ml/cm2·min@10kPa, 25℃) | 25 | 30 | 35 | 60 |
| Standard Retention Rate (%) | > 95 | |||
| Reinforcement Material | PET - PE(4) | |||
| Thickness (μm) | 80 ~ 150 | |||
| Pure Water Wetting Time (s) | < 2,?Instant | |||
Explanation:
1.?Product implementation standard: QB/T01-2015 "PTFE microporous membrane"
? ?QB/T05-2015 "Fluorine material microporous membrane - medical"
2. The above first bubble pressure and flow rate data are typical values
3. The X in the product model row indicates reinforement material?
