Technical Data
| Product Model | X1040 | X1120 | X1200 | X1500 |
| Pore Size (μm) | 0.45 | 1.2 | 2.0 | 5.0 |
| Water Flow Rate (ml/cm2·min@10kPa, 25℃) | 12 | 26 | 30 | 35 |
| Standard Retention Rate (%) | > 95 | |||
| Reinforcement Material | PP(3),?PET(4) | |||
| Thickness (μm) | 100 ~ 150 | |||
| Pure Water Wetting Time (s) | < 2, Instant | |||
Explanation:
1.?Product implementation standard: QB/T01-2015 "PTFE microporous membrane"
? ??QB/T05-2015 "Fluorine material microporous membrane - medical"
2.?The above first bubble pressure and flow rate data are typical values
3. The X in the product model row indicates reinforement material?
